Large Crawler ExcavatorsEC750E

  • 73,500 - 75,300 kg
  • 385 kW
  • 3.3 - 5.16

Rely on a superior performance from the EC750E to do the bigger jobs better, stronger and faster. Equipped with a powerful Volvo D16 engine, the... Read more

Contact us Download the EC750E brochure, with all the details and specifications. (PDF, 2.4MB) More specifications and competitor comparison

Increase productivity and ensure maximum return on investment.

Rely on a superior performance from the EC750E to do the bigger jobs better, stronger and faster. Equipped with a powerful Volvo D16 engine, the machine utilizes advanced technology built on decades of experience, delivering increased horsepower and fuel efficiency – that benefits your bottom line.


Here are the key specifications for this product model. Want more details? Download the brochure or contact us.

Operating weight 73,500 - 75,300 kg
Gross power 385 kW engine speed 1,800 rpm
Bucket capacity 3.3 - 5.16
Lifting capacity, along undercarriage 30,760 kg reach / height 6 / 1.5 m
Max. digging reach 11,460 mm
Max. digging depth 7,210 mm
Breakout force, SAE J1179 (Normal) 323 kN
Breakout force, SAE J1179 (Boost) 342 kN
Tear out force, SAE J1179 (Normal) 311 kN
Tear out force, SAE J1179 (Boost) 329 kN
Overall width feet inches 4,290 mm
Tail swing radius 4,140 mm

Based on machine configuration: 6.6m boom, 2.9m arm, 12 100kg CWT

Image illustration only. Production machines may differ in appearance and features vary between markets and models.


Boom and arm you can rely on

Maximize machine uptime and performance for any job application with the reinforced heavy duty boom and arm.

Customer Support Agreements

Volvo uses the latest technology to monitor machine operation and status, giving you advice to increase your profitability. By having a Customer Support Agreement you are in control of your service costs.

Genuinely Volvo

With functions and properties ideally matched, Volvo attachments are an integrated part of the excavator for which they’re intended – delivering maximum productivity.

Powered by Volvo

Rely on a top performance from the EC750E, featuring a powerful Volvo D16 engine for a fast and efficient operation.

Superior digging performance

The EC750E features superior digging force, particularly when working with hard and heavy materials.

Only with Volvo attachments do you get what you wanted when you bought a Volvo in the first place – maximum productivity and uptime. Volvo develops and offers a wide range of attachments which brings you unmatched flexibility and versatility, making it easy for you to develop job opportunities and to get the job done with increased productivity. Displayed attachments may not be available in all markets. Consult your dealer for specific availability.
