Productivity, new engine technology and convenient service features on two new pavers help ensure laying a high-quality mat is simple for the operator.
Volvo Construction Equipment (Volvo CE) will debut two new asphalt paver models for its North American line-up at ConExpo-Con/Agg 2020 – the P5110B tracked and P5170B wheeled pavers. Built for both heavy commercial and light highway tasks, the machines offer easy maintenance and strong performance coupled with serious fuel savings.
“The P5110B and P5170B give contractors a new heavy eight-foot size class option, meeting demand for mid-size pavers that fall between our existing P4410B and 7000B series models,” says Bill Laing, Product Manager, Road Products at Volvo CE. “We also integrated adaptive Volvo engine speed technology into the 5000 series to give high productivity at a very low 1200 rpm. This results in lower operating costs day in, day out.”
The 5000B series is powered by the latest Volvo D6 Tier 4 Final engine, the same engine used in high production models like the Volvo L60H-L90H wheel loaders. Engine speed, torque and fuel consumption are optimized to provide the best performance and fuel efficiency, averaging 3.7 gallons per hour for the 5110B and 3.3 gallons per hour for the 5170B. Additionally, the Volvo engines have low vibration and extremely quiet operation, around 79.2 dBa.
The P5110B and P5170B pavers are fitted with a large capacity hopper to ensure continuous paving, while durable rolled wings help prevent material build-up and cut cleaning time. Once loaded, sonic sensors regulate the flow and delivery of material. The P5170B also has the option of front wheel assist for added traction and grade-ability.
Both models come with an UltiMat160 screed, which features extensions that can adjust paving width hydraulically from eight feet up to 16 feet. The screed’s front-mounted extension supports head-of-material control in the auger channel, further ensuring a quality finish. The screed’s optional bolt-on extensions provide high quality paving up to 18 feet wide. They can also be added or removed quickly, thanks to Volvo’s quick coupling system.
These models also simplify serviceability thanks to ground-level access to common service areas, filters, hydraulic test ports and fuel/DEF tanks. Greaseless bearings in the auger and conveyor and wear parts in the hopper that are easy to access and replace also make servicing these machines easy.
The P5110B tracked paver and P5170B wheeled paver are backed by the Volvo Lifetime Frame and Structure Warranty, which covers the tractor frame on both machines and the track frame on the P5110B for the entirety of the initial period of ownership. They also come with one year of ActiveCare Direct®, Volvo’s advanced telematics service that provides 24/7/365 active machine monitoring and fleet utilization reporting.
Other features that support productivity and efficiency include:
See the features of the new P5110 and P5170 B Series Volvo Blaw-Knox pavers designed to give you high production and quality finished mats.
